Lifting Hook - 1 Tonne

SKU
IA2756
This lifting hook is designed to lock onto the forks of a forklift or telehandler. The lifting hook allows you to use a forklift or telehandler to lift and move unpalletised loads that cannot be lifted by conventional forks.
€236.89 €291.37

Quickest Available Delivery: Up To 7 Working Days - Ireland Final shipping costs and times are calculated at checkout. Shipping address may affect available delivery methods & times.

In stock

The 1 tonne lift fork hook is "adjustable". This means that instead of locking behind the forks, and therefore being stuck in a single position, these hooks can be mounted at any point along the forks of a forklift or a telehandler. To fix the lifting hook in place you simply move the hook to the position on the forks you need it & tighten the thumb screws. This allows you to easily make adjustments as required to make the lifting and moving of unpalletised loads easier.

Specification

  • Capacity (kg) - 1000
  • Weight (kg) - 15
  • Centre of Gravity (mm) - 125
  • Centres - 220mm

Standard Features

  • Completely adjustable along the fork blade (except taper)
  • Supplied complete with single swivel hook and bow shackle
  • Maximum fork section 100 x 45mm at 220mm centres
  • Zinc plated twist screws for safe attachment to truck
  • Painted bright orange for safety

Operation

  1. Position the forks to the correct distance apart to locate into fork pockets.
  2. Drive forks into fork pockets ensuring thumb screws are suitably retracted.
  3. Locate attachment to required position along the blade of the fork.
  4. Tighten thumb screws at desired position ensuring that they are adequately tightened.
  5. The attachment is now ready for use.
