Torus Wire Fencing

Torus Wire Fencing has been developed taking into consideration common issues faced by those working in the agricultural and farming sectors. Taking inspiration from existing fencing options available for purchase, the Torus Wire Fencing follows a similar knot design to many other options, however an improved design makes the Torus Wire Fencing Knot more resilient. This increases both the strength and longevity of the Torus Wire Fencing, when compared with other wire fencing options.

The Torus Knot is beneficial as it is a high-pressure bonded knot with a continuous stay wire, a feature that allows the knot to be much stronger, more reliable, and ultimately safer than other options available on the market.
The smooth design of the Torus Knot is much safer for livestock and user as the lack of sharp edges majorly decreases the likelihood of accident or injury caused by the knot. This design also makes the Torus Knot stronger than a hinge joint due to the way the design of the knot holds the wire in place using the continuous vertical stay wire.

The Torus Wire Fencing option is a robust high-tensile fencing solution, that can last for decades if installed and used correctly.



Benefits:

As a high tensile fencing option, Torus Fencing does not require annual retightening as the pressures of general weathering are unable to stretch the wire mesh. This keeps the cost of maintenance and repair to a minimum.
The High Tensile Fencing solution ultimately ends up being as cost-effective a choice as mild steel as the lack of maintenance costs balances out the financial implications.

Installation is just as quick as, if not quicker than using other fencing options available for purchase, but requires a different installation method. The High Tensile Fencing option is erected using a post driver that easily positions posts to their required depth.

Torus Wire Fencing is available in a wide range of different specifications to accommodate different livestock needs. This is something that should be taken into deep consideration as the selection chosen should reflect the intended purpose as the wire spacing should be suitable for the surrounding livestock.



Specifications:
R6/85/22 Torus Wire Fencing 100 m Grippled
Wire type: 2.5 mm high tensile Torus Knot
Number of horizontal wires: 6
Net height: 85 cm
Vertical wire spacing: 22 cm

R8/80/15 Torus Wire Fencing100 m
Wire type: 2.5 mm high tensile Torus Knot
Number of horizontal wires: 8
Net height: 80 cm
Vertical wire spacing: 15 cm

R8/80/22 Torus Wire Fencing 100 m
Wire type: 2.5 mm high tensile Torus Knot
Number of horizontal wires: 8
Net height: 80 cm
Vertical wire spacing: 22 cm

R8/80/15 Torus Wire Fencing **250 m**
Wire type: 2.5 mm high tensile Torus Knot
Number of horizontal wires: 8
Net height: 80 cm
Vertical wire spacing: 15 cm

R8/80/22 Torus Wire Fencing **250 m**
Wire type: 2.5 mm high tensile Torus Knot
Number of horizontal wires: 8
Net height: 80 cm
Vertical wire spacing: 22 cm

R8/80/22 Torus Wire Fencing **500 m**
Wire type: 2.5 mm high tensile Torus Knot
Number of horizontal wires: 8
Net height: 80 cm
Vertical wire spacing: 22 cm

R8/80/15 Torus Wire Fencing **400 m**
Wire type: 2.5 mm high tensile Torus Knot
Number of horizontal wires: 8
Net height: 80 cm
Vertical wire spacing: 15 cm

R10/100/15 Torus Wire Fencing 100 m
Wire type: 2.5 mm high tensile Torus Knot
Number of horizontal wires: 10
Net height: 100 cm
Vertical wire spacing: 15 cm

R10/90/5 Torus Wire Fencing 50 m
Wire type: 2.5 mm high tensile Torus Knot
Number of horizontal wires: 10
Net height: 90 cm
Vertical wire spacing: 5 cm

R10/90/8 Torus Wire Fencing 50 m
Wire type: 2.5 mm high tensile Torus Knot
Number of horizontal wires: 10
Net height: 90 cm
Vertical wire spacing: 8 cm

R11/120/15 Torus Wire Fencing 100 m
Wire type: 2.5 mm high tensile Torus Knot
Number of horizontal wires: 11
Net height: 120 cm
Vertical wire spacing: 15 cm

R12/110/5 Torus Wire Fencing 50 m
Wire type: 2.5 mm high tensile Torus Knot
Number of horizontal wires: 12
Net height: 110 cm
Vertical wire spacing: 5 cm

R12/110/8 Torus Wire Fencing 50 m
Wire type: 2.5 mm high tensile Torus Knot
Number of horizontal wires: 12
Net height: 110 cm
Vertical wire spacing: 8 cm

R12/110/8 Torus Wire Fencing **100 m**
Wire type: 2.5 mm high tensile Torus Knot
Number of horizontal wires: 12
Net height: 110 cm
Vertical wire spacing: 8 cm

R12/182/15 Torus Wire Fencing 100 m
Wire type: 2.5 mm high tensile Torus Knot
Number of horizontal wires: 12
Net height: 182 cm
Vertical wire spacing: 15 cm

R13/120/5 Torus Wire Fencing 50 m
Wire type: 2.5 mm high tensile Torus Knot
Number of horizontal wires: 13
Net height: 120 cm
Vertical wire spacing: 5 cm

R13/120/8 Torus Wire Fencing 50 m
Wire type: 2.5 mm high tensile Torus Knot
Number of horizontal wires: 13
Net height: 120 cm
Vertical wire spacing: 8 cm

R13/120/5 Torus Wire Fencing **100 m**
Wire type: 2.5 mm high tensile Torus Knot
Number of horizontal wires: 13
Net height: 120 cm
Vertical wire spacing: 5 cm

R13/120/8 Torus Wire Fencing **100 m**
Wire type: 2.5 mm high tensile Torus Knot
Number of horizontal wires: 13
Net height: 120 cm
Vertical wire spacing: 8 cm

R13/192/8 Torus Wire Fencing 50 m
Wire type: 2.5 mm high tensile Torus Knot
Number of horizontal wires: 13
Net height: 192 cm
Vertical wire spacing: 8 cm

R13/192/15 Torus Wire Fencing 100 m
Wire type: 2.5 mm high tensile Torus Knot
Number of horizontal wires: 13
Net height: 192 cm
Vertical wire spacing: 15 cm

R15/158/5 Torus Wire Fencing 50 m
Wire type: 2.5 mm high tensile Torus Knot
Number of horizontal wires: 15
Net height: 158 cm
Vertical wire spacing: 5 cm

R19/180/5 Torus Wire Fencing 50 m
Wire type: 2.5 mm high tensile Torus Knot
Number of horizontal wires: 19
Net height: 180 cm
Vertical wire spacing: 5 cm
